#### COMPUTER SLIDE RULE

INCLUDES:

1. Slide Calculator
2. Tables for tube selection, floor covering and floor r-values
3. Twenty-three page booklet containing step-by-step instructions on designing a radiant floor heating system, from calculating heatloss to tube layout and pump sizing

COMPLETE DESIGN TOOLS IN A SMALL PACKAGE

The RadPad Sizing Calculator is a powerful tool for quickly and easily answering complex "what if" questions to radiant floor heating system design problems.

SIDE 1 - Answers these questions

• What floor Surface Temperature will be required to heat my space?
• What Water Temperature will be required at design loads?
• What is the maximum Floor Covering R-Value I can use on the floor?
• What happens if I increase the Floor Covering R-Value?
• What happens if I increase the water temperature?
• How can I get more output from the floor?

SIDE 2 - Answers these questions

• What Tube Size should I use?
• What Tube Length is best?
• What Tube Spacing will give the best output?
• What will be the Flow and Head Pressure for pump sizing?
• What happens if I use longer tube circuit lengths?
• How can I reduce head pressure?
• What happens if I use a larger tube?
• How does changing tube spacing affect floor output?

EXCEL WORKBOOK

• Zone by Zone input sheets
• System Summary page
• Report printout

INSTRUCTION GUIDE

1. Getting Started
2. Heat Loss Calculations
3. Floor Output
4. Floor Covering
5. Floor Surface Temperature
6. Average Water Temperature
7. Supply Water Temperature
8. Tube Selection and Size
9. Tube Spacing
10. Total Tube Required
11. Tube Circuit Length
12. Number of Circuits
13. Actual Circuit Length
14. Flow Per Tube
15. Pressure Drop
16. Summarize Circuits
17. Zone Flow
18. Zone Pressure Drop
19. System Flow and Pressure Drop
20. Heating System Design
21. Work Sheets
